#711608 - 08/08/09 03:13 AM STICKY: Every monte bulb part number you need!!!
Joined: Oct 2007
Posts: 1,379
83montecarlo632bbc Offline
Member
83montecarlo632bbc  Offline
Member

Joined: Oct 2007
Posts: 1,379
omaha nebraska
Well heres a list i put together of every part number for every light bulb on the monte ss, i recommend this be a sticky!! If any of these are wrong or im leaving any out let me know please!!



Ash Tray Light Bulb=wagner 1892

Back Up Lamp Bulb=OE TYPE #BP1156

Back Up Lamp Socket=ACDELCO Part # LS2

Brake Light Bulb=OE TYPE #BP2057

Clock Light Bulb=168

Courtesy Light Bulb=original #BP906

Dome Light Bulb=OE TYPE #BP561

Engine Compartment Light Bulb=original #BP93

Glove Box Light Bulb=OE TYPE #BP1895

Headlamp Socket=ACDELCO Part # LS144 (low),ACDELCO Part # PT1899 (high)

Headlight Bulb=4651(high), 4652(low)

High Beam Indicator Light Bulb=OE TYPE #BP161

Hood Light Bulb=original #BP93

Ignition Light Bulb=OE TYPE #BP168

Instrument Panel Light Bulb=OE TYPE #BP168

License Plate Lamp Bulb=OE TYPE #BP194

License Plate Lamp Socket=ACDELCO Part # LS247

Marker Lamp Socket=ACDELCO Part # LS247

Parking Brake Warning Light Bulb=OE TYPE #BP168

Parking Lamp Socket=ACDELCO Part # LS8

Parking Light Bulb=168(in dash), OE TYPE #BP2057

Radio Dial Light Bulb=OE TYPE #BP168

Seat Belt Light Bulb=OE TYPE #BP168

Side Marker Lamp Socket=ACDELCO Part # LS247

Side Marker Light Bulb=OE TYPE #BP194

Stop Socket=ACDELCO Part # LS6

Tail Lamp Socket=ACDELCO Part # LS253

Tail Light Bulb=OE TYPE #BP2057

Trunk or Cargo Area Light Bulb=OE TYPE #BP1003

Turn Signal Lamp Bulb=OE TYPE #BP2057

Turn Signal Lamp Socket=ACDELCO Part # LS248

3rd brake light bulb=OE TYPE #BP1156


1983 monte carlo ss "drag car"
powered by 638 cubic inches of big block power

1985 monte carlo ss "street car"
eventually will be powered by a 434 ci sbc f2 procharged


#711610 - 08/08/09 03:18 AM Re: Every monte light bulb part number you need!!! [Re: 83montecarlo632bbc]
Joined: Oct 2008
Posts: 330
MikePEI Offline
Member
MikePEI  Offline
Member

Joined: Oct 2008
Posts: 330
Charlottetown,PEI,Canada
Good work, Good to have...



81-355/325hp and 87SS original, 1929 Model A Custom powered by Chevy
Mike PEI
#713543 - 08/13/09 04:08 PM Re: Every monte light bulb part number you need!!! [Re: MikePEI]
Joined: May 2008
Posts: 93
MIKE D Offline
Member
MIKE D  Offline
Member

Joined: May 2008
Posts: 93
BROOKLYN, NY
A+++++++++++++++++

#721217 - 09/07/09 03:31 AM Re: Every monte light bulb part number you need!!! [Re: MIKE D]
Joined: Nov 2007
Posts: 382
Shaun1414 Offline
Member
Shaun1414  Offline
Member

Joined: Nov 2007
Posts: 382
Tulsa, oklahoma
Thank you, that was helpful laugh

Last edited by Shaun1414; 09/07/09 03:32 AM.

1987 Monte Carlo SS Aerocoupe. Edelbrock 3706 Intake, Kenwood KDC-mp435u head unit, B&M Street/Strip Shift Kit, Energy Suspension Poly Bushings, Holley 600CFM carb, Hooker Competition Headers, 3 inch X-pipe, 3 inch(in/out) Flowmaster 40's Accel HEI Distributor, MSD Digital Control Module, MSD Coil, Moroso Advance Kit. IceMan Chromoly Crossmember
#721281 - 09/07/09 03:37 PM Re: Every monte light bulb part number you need!!! [Re: Shaun1414]
Joined: Nov 2002
Posts: 623
TURBO Offline
Member
TURBO  Offline
Member

Joined: Nov 2002
Posts: 623
TN Smoky Mtns
Great info. My 87 glove box light is a plug in bulb not a socket like the 1895. Any more info? Again, great find.

Last edited by TURBO; 09/07/09 09:06 PM.


87 SS White/ Saddle,t-top,350/330 hp
#721317 - 09/07/09 05:20 PM Re: Every monte light bulb part number you need!!! [Re: TURBO]
Joined: May 2007
Posts: 469
Rich.S85SS Offline
Member
Rich.S85SS  Offline
Member

Joined: May 2007
Posts: 469
Long Island New York
Awesome! Thanks so much.



1985 SS, Hotchkis suspension kit, Edelbrock shocks and Air Gap RPM intake, Eibach Springs, Hurst quarter stick, GM crate 350HO long block, Edelbrock 650 AVS Thunder carb, MSD ignition, Hooker Headers, Steel cowl hood, Pro-Torque converter. Proud member NYMCC.
#734883 - 10/27/09 09:40 PM Re: Every monte light bulb part number you need!!! [Re: Rich.S85SS]
Joined: Sep 2007
Posts: 821
woodss Offline
Member
woodss  Offline
Member

Joined: Sep 2007
Posts: 821
nh
Thats an exellent list.......Someone should sell a kit that includes all the bulbs for the whole car.

#734887 - 10/27/09 09:52 PM Re: Every monte light bulb part number you need!!! [Re: woodss]
Joined: Nov 2002
Posts: 623
TURBO Offline
Member
TURBO  Offline
Member

Joined: Nov 2002
Posts: 623
TN Smoky Mtns
What about the bulb for the glove box on 87. I see every list stating 1895 but mine is a plug in. Everyone else?



87 SS White/ Saddle,t-top,350/330 hp
#735038 - 10/28/09 04:45 AM Re: Every monte light bulb part number you need!!! [Re: woodss]
Joined: Nov 2008
Posts: 305
gmguy3car Offline
Authorized Vendor
gmguy3car  Offline
Authorized Vendor
Member

Joined: Nov 2008
Posts: 305
Silverdale,Wa
Originally Posted By: woodss
Thats an exellent list.......Someone should sell a kit that includes all the bulbs for the whole car.

Great Idea, I'll give it a shot and create a bulb kit and get the price and see if it sells.
Thanks for posting this 83.





#735078 - 10/28/09 11:56 AM Re: Every monte light bulb part number you need!!! [Re: gmguy3car]
Joined: Sep 2007
Posts: 821
woodss Offline
Member
woodss  Offline
Member

Joined: Sep 2007
Posts: 821
nh
Id buy one - let me know.

#735609 - 10/30/09 12:32 AM Re: Every monte light bulb part number you need!!! [Re: woodss]
Joined: Oct 2007
Posts: 1,379
83montecarlo632bbc Offline
Member
83montecarlo632bbc  Offline
Member

Joined: Oct 2007
Posts: 1,379
omaha nebraska
how about a kit with all led bulbs for the whole car?


1983 monte carlo ss "drag car"
powered by 638 cubic inches of big block power

1985 monte carlo ss "street car"
eventually will be powered by a 434 ci sbc f2 procharged


#735743 - 10/30/09 03:37 PM Re: Every monte light bulb part number you need!!! [Re: 83montecarlo632bbc]
Joined: Sep 2007
Posts: 821
woodss Offline
Member
woodss  Offline
Member

Joined: Sep 2007
Posts: 821
nh
That sounds good........

#743663 - 11/25/09 08:14 PM Re: Every monte light bulb part number you need!!! [Re: woodss]
Joined: May 2007
Posts: 197
ken87aero Offline
Member
ken87aero  Offline
Member

Joined: May 2007
Posts: 197
Bay Area, CA
well guess what im looking for! a light bulb =) lol good stuff..


87 ss aero coupe. rebiult bored out gen1 350, vortec heads, "zz4" style rollers, performer cam, rebiult 200-4r + shift kit. "it's got a little giddy-up to it"
#744598 - 11/29/09 06:19 PM Re: Every monte light bulb part number you need!!! [Re: ken87aero]
Joined: Sep 2007
Posts: 821
woodss Offline
Member
woodss  Offline
Member

Joined: Sep 2007
Posts: 821
nh
Just looked for the LED replacements - 30 bucks for 1 -1157.

#754385 - 01/06/10 05:58 PM Re: Every monte light bulb part number you need!!! [Re: woodss]
Joined: Jan 2001
Posts: 4,336
supernova455 Offline
15+ Year
supernova455  Offline
15+ Year
Member

Joined: Jan 2001
Posts: 4,336
tampa, fl usa
That is a great list. Why can't the owners manual be so simple?
A bulb kit is a great idea, but supply maybe 2-4 bulbs per component in the higher failure areas, or upgraded versions like LEDs.

Supernova455

#763779 - 02/08/10 10:41 PM Re: Every monte light bulb part number you need!!! [Re: supernova455]
Joined: Sep 2009
Posts: 5
Dr.D Offline
New Member
Dr.D  Offline
New Member

Joined: Sep 2009
Posts: 5
Porters Lake, Nova Scotia, Can...
Well done, getting ready to redo wifes 83SS and this list will come in handy. Thanks, Drew.

#784580 - 04/13/10 02:25 PM Re: Every monte light bulb part number you need!!! [Re: Dr.D]
Joined: Sep 2008
Posts: 328
JBreu Offline
Member
JBreu  Offline
Member

Joined: Sep 2008
Posts: 328
Livonia,N.Y.
Saves a big Pain in the bass.GREAT JOB


1984 Monte Carlo sbc bored/stroked to 388 c.i. 514 Dynoed HP.700r4 w/2000 stall,12 Bolt w/4:10
Old Chevy's Don't Die, They Just Get Faster
Best E.T. to date : 12.20 @ 110 MPH All Motor
#936696 - 06/21/12 04:15 PM Re: Every monte light bulb part number you need!!! [Re: JBreu]
Joined: Aug 2010
Posts: 263
tom demarco Offline
Member
tom demarco  Offline
Member

Joined: Aug 2010
Posts: 263
Burlington
incorrect radio light # advanced auto has em by sylvania 73LL

#938730 - 07/10/12 05:05 AM Re: Every monte light bulb part number you need!!! [Re: tom demarco]
Joined: Mar 2012
Posts: 78
TerMonteNatorSS1986 Offline
Member
TerMonteNatorSS1986  Offline
Member

Joined: Mar 2012
Posts: 78
Edmonton, Alberta
Thank You smile

#938766 - 07/10/12 04:34 PM Re: Every monte light bulb part number you need!!! [Re: TerMonteNatorSS1986]
Joined: Feb 2009
Posts: 228
The_Madness Offline
Member
The_Madness  Offline
Member

Joined: Feb 2009
Posts: 228
Gulfport, MS
Excellent list. I put it into a Word document so that I can print it out and keep it in the car.


1984 Monte Carlo SS - currently taking a long-term nap
2000 Dodge Ram 2500 Cummins Turbo Diesel
#940506 - 07/29/12 02:22 AM Re: Every monte light bulb part number you need!!! [Re: The_Madness]
Joined: May 2011
Posts: 200
cjsporl Offline
Member
cjsporl  Offline
Member

Joined: May 2011
Posts: 200
Cape May NJ
i have a better idea... Some person from china sells led bulbs for every part of our car. I'll get the URL.

by the way i did a complete conversion of every light bulb in my car from them. tailights,brake light,dash lights, interior lights,turn signals, side markers. Everything!

under $40.00

#944072 - 09/02/12 03:28 AM Re: Every monte light bulb part number you need!!! [Re: cjsporl]
Joined: Aug 2012
Posts: 214
Cheford Offline
Member
Cheford  Offline
Member

Joined: Aug 2012
Posts: 214
Ottawa, Ontario
Aren't the low beams H4656??


[Linked Image]
#954651 - 12/09/12 04:02 AM Re: Every monte light bulb part number you need!!! [Re: Cheford]
Joined: Nov 2012
Posts: 131
Robert 29 Offline
Member
Robert 29  Offline
Member

Joined: Nov 2012
Posts: 131
Oceano,Ca
Napa Know How.

#1021087 - 03/16/15 10:58 PM Re: Every monte light bulb part number you need!!! [Re: 83montecarlo632bbc]
Joined: May 2014
Posts: 73
Ubowl Offline
Member
Ubowl  Offline
Member

Joined: May 2014
Posts: 73
Cape Coral Fl
What about the turn signal indicator in the dash

#1021089 - 03/16/15 11:04 PM Re: Every monte light bulb part number you need!!! [Re: 83montecarlo632bbc]
Joined: Oct 2003
Posts: 1,068
RoadWarrior Offline
15+ Year
RoadWarrior  Offline
15+ Year
Member

Joined: Oct 2003
Posts: 1,068
Mechanicsburg, Pa
168, 194 or 2825

they're all the same base, the only difference is the output. the factory 168 are only about 38 Lumens, the 194's are 25 lumens, but the 2825 are the brightest at 50 lumens.


MadMax
88 SS, 355 owned since '03
#1028643 - 08/27/15 02:37 AM Re: Every monte light bulb part number you need!!! [Re: 83montecarlo632bbc]
Joined: Jul 2001
Posts: 67
BoiseSS Offline
15+ Year
BoiseSS  Offline
15+ Year
Member

Joined: Jul 2001
Posts: 67
Boise, Id.
New question, are the t top dome lihgts the same as hard top dome?


Steven Payson
Grey Wolf
[Linked Image]
#1028647 - 08/27/15 03:52 AM Re: STICKY: Every monte bulb part number you need!!! [Re: 83montecarlo632bbc]
Joined: Jun 2004
Posts: 346
Bitflipper Online content
15+ Year
Bitflipper  Online Content
15+ Year
Member

Joined: Jun 2004
Posts: 346
Las Vegas, NV
I thought I'd chime in on this thread with my LED lighting experience. After researching the LED light options, I decided to splurge on Sylvania bulbs for the dash after seeing some other people's experience with the cheaper kind burning out a lot. You can buy the high-end Sylvania bulbs for the dash and rear license area here:

http://www.amazon.com/SYLVANIA-2825-Premium-White-Miniature/dp/B00AIJY2ZM

Here is a photo of my dash lit up at night, no assistance from street lights or otherwise. My signature has a photo of the license area under the same conditions.



(And incase someone is judging my mileage - it's a Canadian car so that's km's on the odometer and it's been around once; I replaced the face from an El Camino in a US junkyard when I relocated)

That one dead area in the gear indicator area is somewhat unavoidable due to the bulky indicator mechanism blocking even the brightest light almost completely. Still, never imagined my dash could be so brilliant.

Close to $100 in premium LED lightbulbs to do the dash and license area. The cheap bulbs with the multiple "light pads" on them might work for a time, though from what I hear, they're going to burn out on you in short order.

I hope this is useful info for someone!


[Linked Image]
#1028652 - 08/27/15 03:11 PM Re: STICKY: Every monte bulb part number you need!!! [Re: Ubowl]
Joined: Nov 2012
Posts: 1,156
Ole Blue Offline
Member
Ole Blue  Offline
Member

Joined: Nov 2012
Posts: 1,156
Lugoff, SC
Originally Posted By: Ubowl
What about the turn signal indicator in the dash
You can go to the Album using the link at the top of this(or any) page and in the Search box type in Lamp Bulb Specifications to view every original bulb requirement.
The page I posted there is from my original 'Owner's Manual'.

#1030142 - 09/30/15 07:19 PM Re: Every monte light bulb part number you need!!! [Re: 83montecarlo632bbc]
Joined: Oct 2011
Posts: 16
87ArrowCoupe Offline
Junior Member
87ArrowCoupe  Offline
Junior Member

Joined: Oct 2011
Posts: 16
San Antonio, TX
nice

#1038415 - 04/27/16 01:30 PM Re: STICKY: Every monte bulb part number you need!!! [Re: Bitflipper]
Joined: Apr 2011
Posts: 85
monte_man_2020 Offline
Member
monte_man_2020  Offline
Member

Joined: Apr 2011
Posts: 85
Lisle, IL
I did this with worse result. I did see someone suggested spraying the plastic piece that goes around the bulbs with silver or reflective to make the light bounce off better. Good write up by the way.

#1041750 - 07/22/16 05:51 PM Re: STICKY: Every monte bulb part number you need!!! [Re: 83montecarlo632bbc]
Joined: Apr 2016
Posts: 12
Libraman87SS Offline
Junior Member
Libraman87SS  Offline
Junior Member

Joined: Apr 2016
Posts: 12
New Braunfels, TX
Does anyone know what LED bulb I can use for my engine compartment?
Thanks Mark

#1042695 - 08/23/16 02:18 AM Re: Every monte light bulb part number you need!!! [Re: 83montecarlo632bbc]
Joined: Aug 2016
Posts: 2
JasonPW Offline
New Member
JasonPW  Offline
New Member

Joined: Aug 2016
Posts: 2
Lima, OH
Awesome information! Thanks!

#1044355 - 10/14/16 09:36 AM Re: Every monte light bulb part number you need!!! [Re: JasonPW]
Joined: Jun 2012
Posts: 163
axld Offline
Member
axld  Offline
Member

Joined: Jun 2012
Posts: 163
lakeland,fl
superbrightleds.com. also when I open the doors on my 86 hard top ss. how many lights should be on?


86 SS . Custom Paint. Built 6.0 with LS3 Top End .TSP Custom grind cam. FITECH ecu and harness.TKO 600 5 spd. Quick 9'' / 3.70 Gearing. ZQ8 Spindles. KORE3 12.8'' frt Brake Kit. UMI Rear Adjustable UCA. Rear LCA. UMI Front Chassis Bar. UMI rear shock tower brace. BMR Coil Springs. BMR Rear Sway Bar. N90 17'' Wheels . . SO FAR..............lol.
#1044463 - 10/17/16 05:49 PM Re: STICKY: Every monte bulb part number you need!!! [Re: 83montecarlo632bbc]
Joined: Jul 2011
Posts: 107
Maverick_Monte Offline
Member
Maverick_Monte  Offline
Member

Joined: Jul 2011
Posts: 107
Perry, IA
This list is a BIG help.
I'm doing some upgrades to my '79. Had more than a few folks mention that my brake lights are not the easiest to see during the dayight. I used this post & Rockauto as a guide. Figured I'd replace most of the bulbs around the outside outside and the instrument panel ones as well as they are mostly original and, in the case of the instrument panel, some are burn't out too. Some of my PNs differ from the list, but I figure that is normal with mine being a 3rd gen. I have the OEM PN as well as what RockAuto calls "Maximum Brightness" listed below. Most of the Max Brightness are the PHILIPS CrystalVision series. Thought about LED, but that gets a tad pricey. 3 questions.

  • Do I have accurate OEM and Max Bright PNs?
  • How many of each do I need?
  • Am I missing any that I SHOULD upgrade?
  • Is there a PN for upgrading the engine compartment light socket? The internal mercury switch crapped out on mine, so I ditched it.
  • Any downside in going to the "Maximum Brightness" Bulbs?
  • If memory serves, the 1157 Brake light bulb does the rear turn signal as well?




Thanks in advance,
Russ

Last edited by Maverick_Monte; 10/17/16 05:50 PM.
#1047839 - 02/05/17 01:58 AM Re: STICKY: Every monte bulb part number you need!!! [Re: 83montecarlo632bbc]
Joined: Oct 2014
Posts: 3
reallystoked Offline
New Member
reallystoked  Offline
New Member

Joined: Oct 2014
Posts: 3
Owosso, MI
Has anyone tried either of the two bulbs: Philips 1157 P21/5W Red X-tremeVision LED Exterior
https://www.amazon.com/Philips-1157-X-tremeVision-Exterior-light/dp/B00HWS7XGW

or SYLVANIA ZEVO 2057 Red LED Bulb https://www.amazon.com/SYLVANIA-ZEVO-205...s=zevo+2057+red

I would like to use one of these but I know on the Zevo I couldn't get the bulb to go far enough into the socket to reach the locking mechanize.

Any suggests and/or ideas?

These are for the rear brake/turn signals.

Last edited by reallystoked; 02/05/17 02:04 AM.
Page 1 of 2 1 2

Random Images
1130/thumbs/ResizedImage_1390834192038.jpg
by O.G.
500/thumbs/735146_568533756504755_317567955_n.jpg
by jnw86
500/thumbs/36.jpg
by Phifdawg
776/thumbs/Dec05MonteCarloresize_0021.JPG
by mikeasis
500/thumbs/DFIinstallsmall.JPG
by MY FYN 79
Help MonteCarloSS.com


Recent Contributors
finallySS
Authorized Vendors
Tell them you saw it
on MonteCarloSS.com!


CustomMonteSSParts.com
Dixie Monte Carlo Depot
GSI Interiors
HRpartsNstuff
Mikes Montes
Savitske Classic & Custom
Powered by UBB.threads™ PHP Forum Software 7.6.0
